RF front-end solution delivers transmit power, receive performance, and front-end control within the X-band lattice.
Qorvo® (Nasdaq: QRVO), a leading global provider of connectivity and power solutions, announced an X-band front-end solution that combines high transmit output with low-noise, high-linearity receive performance for active electronically scanned array (AESA) radar. Developed around a quad architecture, the solution reduces RF content inside the array lattice.
System-Level X-Band Architecture
X-band radar systems are increasingly adopting AESAs, including flat-panel phased-array antennas. Lattice spacing limits the area available for the beamformer, FEMs, and power-control devices. External driver amplifiers and discrete PA control and switching circuits consume valuable lattice space and introduce additional interfaces that customers must accommodate in their designs.
Qorvo’s QPX0252 is a four-channel, 7.9 to 12 GHz beamformer IC. Its high transmit output power drives compatible Qorvo FEMs, such as the QPF5012, directly, eliminating the need for external driver amplifiers. Companion Qorvo devices provide GaN PA bias control and RF switching.
“Beamformers are typically designed as stand-alone components, leaving customers to integrate the FEMs, bias control and RF switching around them,” said Diwakar Vishakhadatta, VP, Defense & Aerospace Products at Qorvo. “We developed the QPX0252 as part of the X-band front-end architecture, defining its transmit, receive, and control functions around the requirements of the radar system.”
Selectable Receive Performance
In high-power radar systems, the Qorvo FEM delivers a low system noise figure while the QPX0252 operates in a high-linearity mode. Qorvo’s system analysis shows up to 20 dB higher cascaded input P1dB than other market offerings.
